Domus MODULA-SQR - 9W 24V DC LED Square Inground Light Aluminium IP65 - DRIVER REQUIRED

The MODULA luminaire provides a practical solution for all inground lighting applications including pathways, driveways, courtyards and decks. Utilising a solid aluminium CNC machined external fascia plate in anodised Titanium finish coupled with a 6063 graded aluminium body in a black anodised finish.  The MODULA recessed inground luminaire utilises the latest in Citizen COB technology offering unsurpassed performance and optical lighting control. A polycarbonate housing is provided for concrete applications. The MODULA is a fantastic addition when used as a source for tree up lighting or external fascia, garden walls.

LIMITED STOCKS - WHILE STOCKS LAST!!!

Requires: 24V DC Constant Voltage LED Driver - Wire in Parallel

• Single Colour Temperature 3000K & 5000K available
• Solid Aluminium fascia plate in anodised Titanium finish
• 6063 graded Aluminium body in black anodised finish
• Three Year Replacement Warranty

Specifications:

• Input Voltage: 24V DC*
• Power (W): 9W LED
• IP Rating (IP): IP65
• Lumen Output (Lm): Warm White 3000K - 900Lm  /  White 5000K - 950Lm
• LED Type: Citizen COB
• Colour Temperature: 3000K - 5000K
• CRI: ≥83
• Beam angle (°): 45°
• Dimmable: No
• Lifespan (hrs): 50,000hrs
• Cutout (Ø): Ø105mm

*Requires 24V DC Constant Voltage LED Driver - Wire in Parallel

Dimensions:

• Length: 125mm x Width: 125mm
• Height: 110mm
• Cutout Size: Diameter Ø105mm x Depth 140mm

DOWNLOAD DATA SHEET
